stock no. :
8227
Machine's group :
Surface grinder
Type :
JUNG HF 40
Information request
JUNG HF 40 6 Image(s)
Back
Technical data
Table length
400 mm
Table width
150 mm
Grinding length
400 mm
Grinding width
150 mm
Execution:
    hydraulic
Max. distance from table
    to spindle-centreline
350 mm
Table speeds:
    stepless
       from
2.00 m/min
       up to
20.0 m/min
Automatic vertical feed:
    from
0.0020 mm
    up to
0.013 mm
Diameter of grinding wheel
200 mm
Width of the grinding wheel
16 mm
Grinding wheel speeds:
       from
2800 rpm
Voltage 50 Hz 3x
380 Volt
Grinding spindle motor
2.30 HP
Machine's weight about
900 kg
Overall dimensions machine:
    Length
1300 mm
    Width
1200 mm
    Height
1500 mm

Technical specifications and pictures without guarantee.
