Technical data
Centre height
130 mm
Distance between centres
800 mm
Table length
1214 mm
Table width
140 mm
Max. grinding diameter
260 mm
Max. grinding wheel diamter
200 mm
Taper in spindle:
5 MT
Work piece spindle speed
360 rpm
Grinding spindle speeds:
up to
4500 rpm
Voltage 50 Hz 3x
380 Volt
Grinding spindle motor
2 HP
Machine's weight about
1100 kg
Overall dimensions machine:
Length
2180 mm
Width
1420 mm
Height
1760 mm
Various accessories:
Tailstocks
2 x
Set of centers
Technical specifications and pictures without guarantee.
