Technical data
Min. diameter
1.5 mm
Max. diameter
50 mm
Spindle speeds:
from
150 rpm
up to
2500 rpm
Total stroke
120 mm
Stroke speed:
from
0 s/min
up to
220 s/min
Voltage 50 Hz 3x
400 Volt
Spindle motor
2.2 kW
Total power required
4 kVA
Machine's weight about
900 kg
Overall dimensions machine:
Length
1600 mm
Width
1000 mm
Height
1600 mm
Technical specifications and pictures without guarantee.
