Technical data
Execution:
righthand
Bar diameter round up
3 mm
up to
26 mm
Length of bars max.
3200 mm
Outstanding length min.
450 mm
Feed range
0 - 400 mm/s
Max. Feed force
550 N
Voltage 50 Hz 3x
400 Volt
Power
2 kW
Compressed air from
6 bar
Machine's weight about
750 kg
Overall dimensions machine:
Length
4700 mm
Width
700 mm
Height
1500 mm
Technical specifications and pictures without guarantee.
