Technical data
Centre height
200 mm
Distance between centres
280 mm
Max. grinding diameter
200 mm
Grinding-wheel diameter
125 mm
Taper in spindle:
5 MT
grinding spindle:
Longitudinal way of table
150 mm
Transversal way of the table
140 mm
Slewing range of grinding head:
horizontal
90 °
vertical
90 °
Grinding spindle speeds:
number (steps)
3
from
4500 rpm
up to
7100 rpm
Voltage 50 Hz 3x
380 Volt
Grinding spindle motor
3 HP
Machine's weight about
560 kg
Overall dimensions machine:
Length
620 mm
Width
500 mm
Height
1500 mm
Various accessories:
Set of collets
Set of grinding wheel arbors
Dividing plates
Set of grinding wheels
Grinding wheel guard
Technical specifications and pictures without guarantee.
