stock no. :
21234
Machine's group :
Machining and turning center from bar
Type :
CHIRON FZ 08 KS Magnum
Controller :
GE Fanuc Series 18i-MB5
Technical data
Longitudinal travel (X-axis)
450 mm
Transversal travel (y axis)
270 mm
Vertical travel (z axis)
310 mm
Drill capacity
12 mm
Max. taping diameter M
8
Tool changer:
Number of tools
24
Tool diameter
50 mm
Diameter with free adjacent pockets
100 mm
Tool lenght
160 mm
Max. tool-weight
1.2 kg
Time of tool changing
0.8 / 2.3 sec
Spindle nose:
HSK-A 40
Spindle speeds:
up to
30000 rpm
Rapid traverse:
75 m/min
Voltage 50 Hz 3x
400 Volt
Spindle motor
7 kW
Total power required
14 kW
Various accessories:
Status light
Technical specifications and pictures without guarantee.
