Technical data
Table length
650 mm
Table width
160 mm
Execution:
hydraulic
Max. distance from table
to spindle-centreline
330 mm
Longitudinal travel (X-axis)
483 mm
Transversal travel (y axis)
171 mm
Table speeds:
stepless
from
1.50 m/min
up to
18.0 m/min
Automatic vertical feed:
from
0.0010 mm
Diameter of grinding wheel
178 mm
Width of the grinding wheel
13 mm
Grinding wheel speeds:
from
2880 rpm
Voltage 50 Hz 3x
380 Volt
Grinding spindle motor
2.00 HP
Machine's weight about
850 kg
Overall dimensions machine:
Length
1600 mm
Width
800 mm
Height
1700 mm
Various accessories:
Coolant system
Magnetic plate:
Length
350 mm
Width
160 mm
Technical specifications and pictures without guarantee.
