Technical data
Min. grinding diameter
2 mm
Max. grinding diameter
100 mm
Width of the grinding wheel
200 mm
Grinding wheel:
diameter new wheel
600 mm
diameter used wheel
400 mm
Width
200 mm
Bore
304.8 mm
Speeds:
from
22.5 m/s
up to
45 m/s
Regulating spindle:
diameter new wheel
300 mm
diameter used wheel
180/210 mm
Width
200 mm
Bore
127/152 mm
Speeds:
stepless
from
10 rpm
up to
100 rpm
Voltage 50 Hz 3x
380 Volt
Main motor
18.5 kW
Machine's weight about
4200 kg
Overall dimensions machine:
Length
2500 mm
Width
2100 mm
Height
2200 mm
Various accessories:
Coolant system
Technical specifications and pictures without guarantee.
