Technical data
Units: horizontal
1
Units: vertical
1
Way longitudinal slide:
up to
70 mm
Working way:
up to
60 mm
Swivelling range
4 x 90 °
Work-piece clamping:
with collet
EX 20
Working capacity:
Boring diameter from
0.15 mm
up to
8 mm
Voltage 50 Hz 3x
380 Volt
Table drive
0.4 kW
Machine's weight about
750 kg
Overall dimensions machine:
Length
1200 mm
Width
1120 mm
Height
1600 mm
Technical specifications and pictures without guarantee.
