Table length
|
700
|
mm
|
|
Table width
|
250
|
mm
|
|
Longitudinal travel (X-axis)
|
320
|
mm
|
|
Transversal travel (y axis)
|
220
|
mm
|
|
Vertical travel (z axis)
|
410
|
mm
|
|
Spindle speeds:
|
|
|
|
stepless
|
|
|
|
from
|
56
|
rpm
|
|
up to
|
3150
|
rpm
|
|
Taper in spindle
|
30
|
ISO
|
|
Feeds stepless:
|
|
|
|
longitudinal from
|
8
|
mm/min
|
|
up to
|
1000
|
mm/min
|
|
transversal from
|
8
|
mm/min
|
|
up to
|
1000
|
mm/min
|
|
vertical from
|
8
|
mm/min
|
|
up to
|
1000
|
mm/min
|
|
Vertical quill travel
|
60
|
mm
|
|
Rapid traverse:
|
|
|
|
longitudinal
|
2
|
m/min
|
|
transversal
|
2
|
m/min
|
|
vertical
|
2
|
m/min
|
|
Voltage 50 Hz 3x
|
380
|
Volt
|
|
Motor power
|
1.8
|
kW
|
|
Total power required
|
2.6
|
kW
|
|
Machine's weight about
|
1000
|
kg
|
|
Overall dimensions machine:
|
|
|
|
Length
|
1800
|
mm
|
|
Width
|
1200
|
mm
|
|
Height
|
1500
|
mm
|
